HZS60 Concrete Batching Plant Zoom in
  • Name:

    HZS60 Concrete Batching Plant

  • Minimum Order Quantity:1 Set/Sets
  • Supply Ability:15 Set/Sets per Month
  • Payment Terms:L/C,T/T

Product Description

HZS60 Concrete batching plant adopts JS1000 twin-shaft compulsory mixer, producing homogeneous concrete with good quality in short time. The easily-damaged parts could last for long time, convenient to operate and maintain. It applied the latest design for electronic weighing, computer control and digital display. The electronic weighing system has a buffer device and automatic volume compensation with high accuracy. The sand and gravel feeding system applied inclined belt with great width, the maintenance walkways is installed. It is the ideal choice for producing high-quality concrete.

Quick Details of HZS60 concrete batching plant :

Model Number:HZS60 Concrete Batching Plant
Condition:New
Capacity:60m3/h
Main Mixer:JS1000
Power of Main Mixer:37kw
Feeding Mode:Lifting hopper
Mixing Time:60s
Max Aggregate Size:60/80mm
Discharging Height:3.8m(for customers choice)
Control Mode: Automatic Control System/Central Console Control

Specifications of concrete mixing plant

HZS60 Concrete batching plant
1.Competitive price and quality
2.Compact structure,reliable performance
3.Warranty: 12Month

The layout for HZS60 complete concrete batching plant:

Main features of HZS60 concrete batching plant :

1.Adopt combined structure and modular unit, convenient to install and remove;

2.Mixing and aggregate lifting system adopt JS1000 double-shaft compulsory concrete mixer which offers high quality and efficient mixing;

3.Aggregate batching system adopts PLD1600 concrete batcher which offers efficient and accurate measurement;

4.Powder lot is electronic measured, highly accurate dosing;

5.Water is flow-metering, simple and practical, highly accurate dosing.

Main technical data of concrete mixing plant HZS60

Type

HZS60 concrete batching plant

Productivity in theory

60m³/h

Mixer

JS1000

Maximum aggregate diameter

80mm

Aggregate bins volume

3X13m³

Aggregate feeding method

Conveying belt

Batcher

PLD1600

Aggregate weighing

3000kg ±2%

Cement weighing

600kg ±1%

Water(flow-metering)

400kg ±1%

Overall dimension(during operating)

        (LXWXH)



33.8mX14.8mX10.8m

Total power

110kw

Total weight



46Ton

Control

Fully automatic

Cement silo(optional)

Required on clients' demand, 50T、100T available

Cement screw(optional)

Each cement silo equipped with one φ219 screw
